Research on target detection and tracking algorithms in real-time video streaming
, , oraz
29 wrz 2025
O artykule
Data publikacji: 29 wrz 2025
Otrzymano: 27 sty 2025
Przyjęty: 09 maj 2025
DOI: https://doi.org/10.2478/amns-2025-1130
Słowa kluczowe
© 2025 Wenjing Yu, Daitao Wang, Hongjun Qiu and Jianbin Zhong, published by Sciendo.
This work is licensed under the Creative Commons Attribution 4.0 International License.
Figure 1.
Figure 2.
Figure 3.
Figure 4.
Figure 5.
Figure 6.
Figure 7.
Figure 8.
Figure 9.
Figure 10.
Figure 11.
Comparison of improved inter-frame difference method on UAV123 dataset
| Detection method | Precision% | MAP% | Recall% | FPS (f/s) | |||
|---|---|---|---|---|---|---|---|
| Car | Bus | Van | Others | ||||
| Interframe difference method | 86.09 | 86.01 | 84.37 | 84.87 | 85.34 | 84.68 | 24 |
| Recluster the anchor box only | 87.27 | 88.98 | 86.36 | 85.54 | 87.04 | 86.53 | 29 |
| Only after improving the extraction network | 89.56 | 87.88 | 88.36 | 86.41 | 88.05 | 86.41 | 25 |
| Only after improving the loss function | 90.15 | 87.54 | 91.29 | 87.09 | 89.02 | 87.96 | 30 |
| Improved interframe difference method+Mean shift | 96.62 | 94.28 | 94.68 | 93.22 | 94.70 | 89.92 | 32 |
Comparison of results of different target detection algorithms
| Detection method | Precision% | MAP% | Recall% | FPS (f/s) | Parameter quantity/M | GFLOPs/G | |||
|---|---|---|---|---|---|---|---|---|---|
| Car | Bus | Van | Others | ||||||
| Faster-RCNN | 89.63 | 88.36 | 90.88 | 88.21 | 89.27 | 85.96 | 11 | 51.1 | 124.1 |
| SSD-512 | 87.84 | 86.43 | 85.64 | 87.7 | 86.90 | 84.24 | 15 | 47.6 | 129.7 |
| YOLOv3 | 84.36 | 85.06 | 85.61 | 86.07 | 85.28 | 83.32 | 8 | 48.7 | 109.7 |
| YOLOx | 85.97 | 86.81 | 86.72 | 85.10 | 86.15 | 82.56 | 21 | 38.1 | 114.28 |
| YOLOv7 | 87.18 | 88.58 | 87.93 | 89.52 | 88.30 | 86.36 | 23 | 49.8 | 117.3 |
| OURS | 96.62 | 94.28 | 94.68 | 93.22 | 94.70 | 89.92 | 32 | 37.4 | 112.9 |
MOT16 comparison experiment
| Method | Accuracy | Precision | Recall | MT | ML | MOTA | IDF1 | IDSW |
|---|---|---|---|---|---|---|---|---|
| DeepSORT2 | 95.37% | 93.72% | 94.54% | 35.21% | 18.18% | 62.53 | 61.20 | 894 |
| JDE | 94.15% | 93.89% | 94.02% | 35.72% | 17.21% | 63.39 | 67.36 | 1022 |
| RAR16 | 87.14% | 85.18% | 86.15% | 33.76% | 18.62% | 61.22 | 64.33 | 560 |
| TAP | 92.14% | 90.73% | 91.43% | 37.84% | 19.97% | 65.50 | 67.31 | 839 |
| CNNMTT | 94.59% | 93.41% | 94.00% | 37.59% | 20.74% | 68.06 | 71.49 | 1106 |
| POI | 94.48% | 94.12% | 94.30% | 38.74% | 21.42% | 63.42 | 70.86 | 699 |
| TubeTK | 95.39% | 95.37% | 95.11% | 39.20% | 17.48% | 69.47 | 71.39 | 1185 |
| CTracker | 96.18% | 96.18% | 96.37% | 40.18% | 17.84% | 71.30 | 72.05 | 1244 |
| OURS | 97.57% | 98.82% | 98.19% | 43.86% | 16.62% | 75.76 | 73.37 | 1376 |
Cloud server configuration
| Module | Model/Version |
|---|---|
| Internal memory | 4 Cores |
| Graphics card | 32GB |
| Hard disk | Tesla V108 |
| Operating system | Ubuntu |
| Python | 3.8.15 |
| CUDA | 11.8 |
| CuDnn | 8.2.0 |
MOT17 comparison experiment
| Method | Accuracy | Precision | Recall | MT | ML | MOTA | IDF1 | IDSW | FP | FN |
|---|---|---|---|---|---|---|---|---|---|---|
| DeepSORT2 | 96.76% | 94.62% | 95.43% | 38.34% | 17.45% | 64.78 | 63.56 | 1534 | 22746 | 143976 |
| JDE | 95.55% | 94.65% | 93.49% | 39.03% | 16.34% | 65.43 | 68.40 | 1735 | 22420 | 193791 |
| RAR16 | 90.56% | 87.25% | 88.43% | 36.51% | 17.35% | 62.90 | 64.78 | 1575 | 19527 | 135461 |
| TAP | 94.50% | 92.07% | 93.01% | 38.52% | 17.43% | 66.34 | 68.50 | 1903 | 18811 | 183747 |
| CNNMTT | 95.43% | 94.20% | 93.94% | 39.07% | 19.34% | 68.96 | 75.63 | 2154 | 15345 | 184952 |
| POI | 95.32% | 95.38% | 95.30% | 40.39% | 21.07% | 65.04 | 72.11 | 1865 | 22966 | 167528 |
| TubeTK | 96.03% | 96.12% | 96.09% | 43.56% | 16.40% | 71.33 | 73.75 | 2287 | 16778 | 168269 |
| CTracker | 96.77% | 96.84% | 97.14% | 45.43% | 15.45% | 73.986 | 72.94 | 2335 | 15549 | 149950 |
| OURS | 98.91% | 99.43% | 99.52% | 49.45% | 14.34% | 80.61 | 75.37 | 3408 | 10184 | 129203 |
